Compressed air fittings and tubing form the critical fluid infrastructure of any automated system, delivery mechanism, or pneumatic circuit. Selecting the right combination depends directly on your system’s target operating pressure, chemical environment, and flexibility requirements.

One-Touch & Push-In Pneumatic Fittings

Modern automation relies heavily on push-in fittings because they permit instant toolless connection and disconnection, reducing assembly labor.

An industry-standard straight union built from high-strength polybutylene terephthalate (PBT) using a push-pull claw system. It securely locks 6 mm OD tubing and handles severe pressure envelopes from -0.95 bar vacuum up to 14 bar.

A heavy-duty, 360-degree rotating elbow fitting crafted from nickel-plated brass and fitted with an NBR seal. It transitions a rugged R1/2 male thread down to a 12 mm push-in line, providing space-saving routing around tight actuator valves.

Uses a highly specialized profile seal that demands up to 30% lower tube insertion force while guaranteeing a perfect mechanical vacuum-to-pressure seal up to 1 MPa (10 bar). Standardized to connect a 10 mm OD line to a 10 mm OD line.

Squeezes dual-line splits cleanly into compact machinery layouts, taking a single 8 mm source and splitting it equally into two 8 mm outputs. Built using lightweight PBT resin shells.

Specialized Pneumatic Tubing

The chemical makeup of your air hose determines its bend radius, burst resistance, and long-term durability in high-cycle automation chains.

Premium blue polyurethane line with a 6 mm outside and 4 mm inside diameter. Highly kink-resistant with a tight 16 mm minimum bending radius, making it optimized for high-cycle dynamic applications like moving robot energy chains.

A thick-walled 10 mm OD / 7 mm ID industrial pneumatic hose configured for larger volumetric air delivery up to 10 bar fluid pressure lines. Resists ambient temperatures stretching from deep freeze (-35°C) up to a searing +60°C environment.

Highly calibrated blue 8 mm outer diameter line distributed in 25-meter bundles for general industrial workbench air delivery and manual tooling setups. Rated for reliable 9 bar operation.

Fitting & Tubing Selections:

What is the outer diameter (OD) of the tubing you are working with (e.g., 4mm, 6mm, 8mm, or 12mm)?
What thread type do your air manifolds or valve banks require (e.g., G-thread, R-thread, or NPT)?
Will the line be stationary or exposed to constant motion/flexing on an automated arm?
Straight? Elbow? Tee? one touch? collar type?
Body materials such as stainless steel, brass, pvc, nylon or colors.
